4LPA

4LPA Pro

• Elements/Channels: 96, 32

• Frequency:  Phasedarray probe 2.2/3.6MHz, linear probe 7.5/10MHz

• Scanning Depth: Phasedarray probe 20-240mm, Linear 20-100mm, adjustable

• Field of view: Phasedarray probe R80，Linear 25mm

• Screen: Smart phone or tablet screen

• Supporting system: iOS, Android, Windows

• Display mode: B, B/M, Color, PDI, PW

•  Frame rate: 18f/s

•  Gain: 30db-105db

•  Dynamic Range: 40/50/60/70/80/90/100/110

•  Noise reduction: 0-1-2-3-4

•  Image gray scale: 256 level

•  Image/Video Storage: Store on mobile phones, Tablet PC

•  Measure: distance, area, obstetrics and other;

•  Power: by built-in lithium battery, 1350mAh

•  Battery working time: 1hours

•  Size/Net Weight: 110mm×50mm×18mm, 120g

>>Catalog Download

• Elements/Channels: 96, 32

• Frequency:  Phasedarray probe 2.2/3.6MHz, linear probe 7.5/10MHz

• Scanning Depth: Phasedarray probe 20-240mm, Linear 20-100mm, adjustable

• Field of view: Phasedarray probe R80，Linear 25mm

• Screen: Smart phone or tablet screen

• Supporting system: iOS, Android, Windows

• Display mode: B, B/M, Color, PDI, PW

•  Frame rate: 18f/s

•  Gain: 30db-105db

•  Dynamic Range: 40/50/60/70/80/90/100/110

•  Noise reduction: 0-1-2-3-4

•  Image gray scale: 256 level

•  Image/Video Storage: Store on mobile phones, Tablet PC

•  Measure: distance, area, obstetrics and other;

•  Power: by built-in lithium battery, 1350mAh

•  Battery working time: 1hours

•  Size/Net Weight: 110mm×50mm×18mm, 120g

>>Catalog Download
